Nickel 200 UNS N02200 Steel Pipe Outer Diameter 12 Mm Wall Thickness 12 Mm

Name: Nickel 200 UNS N02200 Steel Pipe Outer Diameter 12 Mm Wall Thickness 12 Mm
Brand: TOBO
Price: 1 USD

Buy cheap Nickel 200 UNS N02200 Steel Pipe Outer Diameter 12 Mm Wall Thickness 12 Mm product

Brand Name : TOBO

Model Number : Nickle Alloy 200

Certification : SGS/ABS/LR/TUV/DNV/BIS/API/PED

Place of Origin : China

MOQ : 1 PCS

Price : Based on the number

Supply Ability : 10000t/month

Delivery Time : 15-30 workdays

Packaging Details : Plastics+wooden

Application : Structure Pipe,Oil Pipe

Technique : Hot Rolled,Cold Drawn

Usage : Construction Structure,super heater

Product name : Nickel Alloy Steel Pipe

Alloy or not : Is Alloy

Thickness : Customized

Contact Now

Nickel 200 UNS N02200 Steel Pipe Outer Diameter 12 mm Wall Thickness 12 mm

Introduction

Nickel 200 is a solid solution strengthened, commercially pure wrought materials with excellent mechanical properties and resistance to corrosion. It also has exceptional resistance to caustic alkalis at different concentrations and temperatures. However, the corrosion resistance is better in de-aerated acid. The alloy has low gas content and vapor pressure, and high thermal and electrical conductivities

Physical Properties

The following table shows the physical properties of Nickel 200 alloy.

Properties	Metric	Imperial
Density	8.89 g/cm3	0.321 lb/in3
Melting point	1435-1446°C	2615-2635°F

Mechanical Properties

The mechanical properties of Nickel 200 alloy are displayed in the following table.

Properties	Metric	Imperial
Tensile strength (annealed)	462 MPa	67000 psi
Yield strength (annealed)	148 MPa	21500 psi
Elongation at break (annealed prior to test)	45%	45%

Thermal Properties

The thermal properties of Nickel 200 alloy are given in the following table

Properties	Metric	Imperial
Thermal expansion co-efficient (@20-100°C/68-212°F)	13.3 µm/m°C	7.39 µin/in°F
Thermal conductivity	70.2 W/mK	487 BTU.in/hrft².°F
